MF960C
Handheld terminal, equipped with OC Linux or Android of your choice.
The terminal is suitable for any trade and service enterprises both mobile and stationary outlets.
Contact our experts Download Brochure
MF960C Features
  • 4-inch Display
    4-inch display with high resolution
  • Linux or Android
    Operating system of your choice
  • Cost-effective
    Optimal combination of improved performance and cost
  • ОS
    Linux 4.14, Android 10
  • Screen
    4-inch capacitive touch screen,
    480 × 800 pixels
  • CPU
    Dual-core ARM Cortex-A53, 1.3 GHz
    Quad-core 64-bit ARM Cortex-A53 , 1.4 GHz
  • Communications
    4G/3G/2G,
    Wi-Fi, Bluetooth
  • Memory
    256 MB RAM + 512 MB FLASH,
    Micro SD (TF card) up to 32 GB
    8 GB eMMC + 1 GB LPDDR3,
    16 GB eMMC + 2 GB LPDDR3 (optional)
  • Wi-Fi
    2.4G, 2.4G + 5G (optional)
  • Bluetooth
    Bluetooth BT 4.2
  • Speaker
    8 Оhm
  • Camera
    0.3 MP rear camera (optional)
  • Card Slots
    2 Micro SAM + 1 Micro SIM
    or 1 Micro SAM + 2 Micro SIM
  • Peripheral Ports
    1 USB 2.0 Type C (OTG)
  • Battery
    3.7 V / 2600 mAh
  • Power Supply
    Input: 100-240 VAC, 50 / 60 Hz
    Output: 5.0 VDC, 2.0 A
  • Printer
    High-speed thermal printer: 60 mm/s (30 l/s)
    Paper width - 58 mm, diameter - 40 mm
  • Certificates
    PCI PTS 6.x, EMV L1 & L2, EMV
    Contactless L1, qUICS L2, MasterCard PayPass, Visa PayWave, American ExpressPay, Discover DPAS, CE, RoHS, TQM
  • Environmental
    Operating temperature : -10°C ~ +50°C
    Storage temperature : -20°C ~ +60°C
    Relative humidity : 10% ~ 90%, non-condensing
  • Keyboard
    10 numeric buttons,
    5 function buttons
  • Audio
    Speaker or buzzer
  • Magnetic card reader
    Tracks 1/ 2/ 3, double-sided
  • IC card reader
    EMV L1 & L2
  • NFC card reader
    MasterCard Contactless & Visa PayWave
    ISO / IEC 14443 Type A/B, Milfare®
  • Dimensions and Weight
    172.4 mm × 80 mm × 64 mm (L × W × H)
  • Operating conditions
    Operating temperature: -10°C ~ 50°C
    Storage temperature: -20°C ~ 70°C
    Humidity: 5% ~ 93%
    Non-condensing
