Smart payment terminal M1
M1 smart payment terminal boasts exceptional performance and
is compatible with all types of cards. Additionally, it can be
outfitted with an optional second screen, providing a platform for
captivating brand advertisements.
Contact our experts Download Brochure
M1 Features
  • 6-inch
    High resolution 6″ HD display,
    perfect size for mobile and
    portable
  • Second screen
    Optional 2nd screen for brand advertising and Tx amount display
  • Performance
    Running multiple apps in the background
  • ОS
    SmartDroid® based on Android®
  • Screen
    6.5" inch HD, 1600×720
    Optional: 2nd screen for amount display
  • CPU
    High Performance Quad-core Cortex® CPU
  • Communications
    4G/3G/2G,
    Wi-Fi, Bluetooth
  • Memory
    1GB RAM, 8GB eMMC
    Оptional: 2GB RAM, 16GB eMMC
  • Wi-Fi
    2,4G/5G, support 802.11 a/b/g/n
  • Bluetooth
    BT 5.0
  • Geolocation
    GPS / GLONASS / BeiDou / Galileo
  • Speaker
    8 Оhm
  • Camera
    Rear: 5MP AF with flash
    Front: 2MP FF (optional)
  • Card Reader
    Magnetic card reader
    Smart card reader
    Contactless card reader
  • QR Scanner (optional)
    0.3MP 1D/2D hardware decoding
    barcode scanner; 3 mil accuracy
  • Keys
    function buttons, 1 power button
  • Card Slots
    2 SIM + 2 SAM
    2 SAM + eSIM (optional)
  • Peripheral Ports
    1 Type C USB 2.0 OTG
    1 Pogo Pin
    1 Micro SD slot, support up to 256GB
  • Battery
    7.4V 2700mAh
    Li-ion rechargeable
  • Power Supply
    Input: 100~240V AC 50/60Hz
    Output: 5.0V DC 2.0A
  • Printer
    2" High-speed thermal printer
    Paper roll: 58×40mm
  • Docking Base
    Charging Only (optional)
    Multifunctional (optional)
  • Certificates
    PCI PTS 6.x, EMV L1&L2, EMV CTLS
    L1, PayPass, PayWave, ExpressPay, DPAS,
    TQM, CE, FCC, RoHS, BIS
  • Environmental
    Operating temperature : -10°C ~ +50°C
    Storage temperature : -20°C ~ +60°C
    Relative humidity : 10% ~ 90%, non-condensing
